Dana Glasslined Water Heater - Uae/India/Africa/Qatar/Bahrain/Kuwait

We M/s DANA WATER HEATERS & COOLERS FACTORY LLC( A Division of DANA Group[www.danagroups.com] are proud to announce the successfulcommissioningof our Fully Automatic Online Dry PowderEnamelingPlant which utilizes State-of-the-art Italian Technology to Manufacture World Class Boilers.
With the installation of this ulta-modern conveyorised plant we are able to manufactureup-to600 boilers/shift or 1200 boilers/day,thus making usamong-stthe TOP 3 manufacturers in the middle east.
We are complying with IEC60335-2-21:2002+A1:2004+A2:2008which deals with the safety of electric storage water heaters for household and similar purposes and intended for heating water below boiling temperature, their rated voltage being not more than 250 V for single-phase appliances.
Glass lined DWH are highly corrosive-resistant as compared to other models made from stainless steel, galvanized steel,ungalvanized steel, and resin coated boilers. Glass lining provides better quality than copper tanks since glass lining by its very nature is not an alloy.
The water heater has been manufactured in an ISO 9001:2008 certified Quality environment and are made from highest quality materials and components in accordance with the highest international standards and utilizing modern technology. It is designed to provide many years of high and reliable performance.


MODEL:- DANA “Glasslined” Water Heater
Capacity
50ltr/80ltr/100ltr/200 Ltr/300 Ltr
Mounting
Vertical/Horizontal
Outer Body
Superior Quality Steel with Electrostatic Powder Coating
Inner Boiler
Circular Welded Steel Tank with Titanium Enameling
Insulation
High Density Polyurethane foam
Element
Long-Lasting specially designed Italian element
Power Specifications
Rated Voltage 220-240V/50 Hz- 60Hz/1200-1500Watts
Thermostat
Adjustable 30C-90C Rating-15Amp/73C
Magnesium Anode
Included
Color
Brilliant White(Other colors available on request)
Testing Pressure
12 Bar
Max. Working pressure
8 Bar
Safety Valve
Included
Operation(Pilot)Lamp
Present
External Thermometer
Present
Earthing Connection
Present
Warranty
Against leakage 5yrs
STANDARD FEATURES:-
§ INNER TANK :-The inner tank of DANA GLASSLINED is circular welded & is Titanium Enameledto provide ultimate protection against corrosion.
§ INSULATION:-The thick CFC-free Polyurethane foam insulation helps in excellent heat retention and economical electrical consumption.
§ HEATING ELEMENT :-Superior Quality Italian element(screw-type) which is ergonomicaly designed for efficient heating and cutting down electricity costs.
§ THERMOSTAT:-Plug-in type auto-cutoff thermostat which ensures optimal temperaturemaintenance.
§ MAGNESIUM ANODE:-Specially designed thick Magnesium alloy anode ensures maximum protection from corrosion.
§ OUTER BODY :-The Outer Body of DANA Glasslined is made up of high quality steel with high gloss epoxy polyester electrostatic powder coating to provide effective protection against corrosion in varied climatic conditions.
§ SPLASH-GUARD TECHNOLOGY :-Directs incoming cold water to the bottom of the boiler,thereby eiminating the mixture of hot and cold water.This mechanism ensures continous supply of hot water at all times.
§ SAFETY VALVE :-Twin function non-return cum safety valve which maintains pressure inside boilder,hence prevents expansion of inner boiler tank,in event of thermostat failure.The non-return function helps to retain water inside the tank inorder to prevent damage to the heating element

We are exporting our water heaters to Qatar(Doha), SaudiArabia(Dammam), Kuwait,Iraq,Bahrain(Manama), Nigeria, Kenya, Uganda, Mauritius, Sudan, Africa, Morocco, Algeria, Sudan, Syria, Jordan, Burundi, Comoros, Djibouti, Ethiopia, Kenya, Madagascar, Libya, Mauritius, Rwanda, Seychelles, Somalia, Tanzania Rep and Uganda,Malta,Burundi,Kazakhstan,Armenia,Azerbaijan and various other African,European and South east Asian destinations.
We look forward to your inquiries,so that we may offer you most competitive prices .
Kind Regards
Ankur / Sreejith
00971-50-7983153 / 00971-50-7445248
DANA WATER HEATERS & COOLERS FACTORY LLC

(A DivisionofDANA Group)
(An ISO 9001:2008 Certified Company)
UAE Head Office :- Suite no 513,Lootah bulding,Nasser Square Deira,Dubai-UAE
Tel :-+971-4-2217273Fax :-+971-4-2215940
Website:-http://www.danagroups.com
Email:-ankur@danagroups.com//drdana@eim.ae

AllourBrochures can be downloadedfromhttp://www.danagroups.com/downloads/
